ASSEMBLY EQUIPMENT, MATERIALS, INSPECTION AND PROCESS CONTROL

Please double click the Logo to visit the listed company website.



Click to visit the Air-Vac Engineering website.

Rework & Repair

SMT attachment and rework equipment for QFPs, BGAs, MicroBGAs, CSPs, Flip Chips, SOs, PLCCs and connectors. PTH rework and selective soldering.

Click to visit the Conveyor Technologies website.

Conveyor Systems

PCB Conveyors, peripherals and workstations

Click to visit the Precision PCB website.

Depaneling

Stand alone and in-line PCB depanelization routers.

Click to visit the Fuji America website.

Pick And Place

High speed and flexible placers, screen printers, adhesive dispensers, and software solutions for PCB assembly.

Solder Reflow And Adhesive Curing Ovens

Click to visit the BTU website.

High Temperature Processing Furnaces





Forced convection solder reflow and adhesive curing ovens for electronic manufacturing applications.

Specialized furnaces for wafer bumping, die attach, underfill cure, package sealing, thickfilm firing, brazing, sintering and heat treating.

Click to visit the MVP Machine Vision Products website.

MVP Machine Vision Products

MVP provides benchtop and in-line AOI systems for Assembled PCB inspection. Coverage includes solder paste, pre-reflow,
post-reflow/wave, and inspection of SMT and mixed technology boards. MVP offers 2D and 3D inspection and state of the art, user friendly, measurement and process control capabilities.

Click to visit the FocalSpot website

X-Ray Inspection Systems

FocalSpot Inc. is a worldwide leader in design and manufacturing of affordable X-Ray Inspection Systems providing sales, service, applications support and training. Our X-Ray Products include: The Verifier and Verifier HR which feature : Small profile 32” x 34” footprint, 16”x 18” board size capability, up to 90 KVA, 5 micron focus for BGA inspection and measurement and up to 650 times magnification. The Concept FX which feature tube sizes up to 130 KVA, 20”x24” board sizes, 2- 6 axis sample manipulation, 5 micron focus, compact  44’ x 38” footprint , 450 x magnification and 3 imaging processor options.

Click to visit the SolderMask website

Stencils

SolderMask, Inc –  manufacturers, Laser Cut Stainless Steel Solder Paste Stencils, Stepped Stencils, Foil ONLY Stencils, Epoxy Stencils, Short run Prototype Stencils with fixture, Micro BGA and BGA rework stencils, Hybrid Stencils (Apertures Chemically etched and Laser Cut), Relief Stencils / Stacked Stencils, Large Area Stencils (LAS). Biggest one to date is 30.5" x 53", metal stiffeners for flexible panels and is a licensed by DEK  to manufacture Vector Guard stencils.

Click to visit the Totech website.

SUPER DRY, MSD Control Cabinets

SUPER DRY was the first dry cabinet introduced in many Japanese Semiconductor factories. SUPER DRY is widely used in Asian, European, and American factories. With SUPER DRY, the moisture related defects of IC packages and Printed Circuit Boards (PCBs) can be effectively and easily reduced or prevented. And with the introduction of lead-free processes the proper handling and care of MSD will become even more critical. A wide variety of cabinet sizes and shelves and options such as nitrogen purging are offered. Lizem Technologies is the distributor for SUPER DRY in North America.

Click to visit the Sono-Tek website.

Spray Fluxer

Ultrasonic spray fluxers for wave soldering.

Click to visit the EMC Global website.

Stencil & Batch

Cleaning Fixtures

Stencil and batch cleaners. Fixtures and composite materials.

Click to visit the Technical Devices website.

Wave Soldering, Aqueous Cleaners

Wave soldering & aqueous cleaning machines; solder recovery systems.

Click to visit the Cogiscan website.

Material Tracking, Traceability

and Control

Cogiscan is focused on automating material control for electronics manufacturing. Cogiscan is an industry leader in WIP and Inventory Tracking, Traceability, Line Set-Up Validation, and MSD Control.

Click to visit the Heraeus website.

Adhesives, Solder Paste,

and Wave Solder Flux

No-clean & water soluble solder pastes, SMT adhesives, and wave solder fluxes.

Click to visit the Metallic Resources website.

Metallic Resources, Inc

Metallic Resources manufactures Electrolytic bar solder. This is the purest solder available from any source. It is available in eutectic,  no-lead formulations and wire solder.

Click to visit the EKRA America website.

Screen/Stencil Printers

Screen Printers for SMT, semiconductor, hybrid, LTCC, and wafer bumping applications. Stand alone and in-line models including handlers.
